        Micro SD Storage Board TF Card Reader Memory Shield Module SPI for Arduino

        £2.49

        9 in stock

        Micro SD Storage Board TF Card Reader Memory Shield Module SPI for Arduino

        £2.49

        SKU: ARD-SHI-059 Category: Shields and Accessories Tags: arduino, Card Reader, Memory Shield, Micro SD, SPI, Storage Board
        Product Categories
        • 3D Printer
          • Controllers
          • Filament
          • Kits
          • Parts & Accessories
        • Arduino
          • Boards
          • Kits
          • Shields and Accessories
        • Cooling
          • Fan Guards
          • Fans
          • Heatsinks
        • Drone
        • Drones and More
          • Accessories
          • Antennas
          • Components
          • Drones
          • Kits
        • Electronics
          • Access Control
          • Cable
          • Components and Sensors
          • DIY Kits
        • LED Lighting
          • Accessories
          • Beads
          • Bulbs
          • Controllers
          • DMX
          • Downlights
          • Panel
          • Strips
        • Mechanical
          • Bearing
          • Bearings
            • Ball
            • Bushings
            • Flange
            • Grooved
            • Linear
            • Miniature
            • Needle
            • Self Aligning
            • Self Lube
            • Taper Roller
          • Fluid Transfer
          • Magnets
          • Mounts and Supports
          • Pulleys and Coupler
          • Rails and Carriage
          • Rods
          • Rods and Carriages
          • Timing Belt
        • Microcontrollers
        • Miscellaneous
        • Motors
          • Accessories
          • Coreless
          • DC Motors
          • Drivers
          • Spindle
          • Step
        • Other
        • Power Supply
        • Raspberry Pi
          • Boards and Kits
          • Shields and Accessories
        • Robotics
          • Components
          • Kits
        • Uncategorised
        • Virtual Reality
        • Description
        • Additional information

        Description:

        Micro SD Storage Board TF Card Reader Memory Shield Module SPI for Arduino

        Features:

        • Supports Micro SD Card, Micro SDHC card (high-speed card)
        • The level conversion circuit board that can interface level is 5V or 3.3V
        • Communication interface is a standard SPI interface
        • Control Interface: A total of six pins (GND, VCC, MISO, MOSI, SCK, CS), GND to ground,
        • VCC is the power supply, MISO, MOSI, SCK is the SPI bus, CS is the chip select signal pin.
        • 3.3V regulator circuit: LDO regulator output 3.3V as level converter chip, Micro SD card supply.
        • Level conversion circuit: Micro SD card into the direction of signals into 3.3V, MicroSD card toward the
          direction of the control interface MISO signal is also converted to 3.3V, general AVR microcontroller system can read the signal.
        • Micro SD card connector: Yes since the bomb deck for easy card insertion and removal.
        • Positioning holes: 4 M2 screws positioning hole diameter of 2.2mm, easy to install positioning, to achieve inter-module combination.

        Specifications:

        Power Supply: 4.5V – 5.5V, 3.3V voltage regulator circuit board
        Positioning Holes: 4 M2 screws positioning hole diameter of 2.2mm
        Control Interface: GND, VCC, MISO, MOSI, SCK, CS
        Size: 45 x 28mm
        Net Weight: 6g
        Package Weight: 16g

        What you will receive:

        1 x Micro SD Board

        Weight30 g
        EAN

        Does not apply

        Brand

        Makers Hut
