DC-DC Adjustable Step-up Boost Power Converter Module XL6009 Replace LM2577

Description

DC-DC Adjustable Step-up Boost Power Converter Module XL6009 Replace LM2577

Specification:

Size: 42mm x 20mm x 10mm
Full Load Temperature Rise: 40
Load Regulation: 0.5%
Voltage Regulation: 0.5%
Dynamic Response Speed: 5% 200uS
Input Voltage: 3-30V
Input Current: Max 4A
Output Voltage: 4-35V(Adjustable)
Output Current: Rated current 3A MAX ( Heat-sink Needed)
No Load Consumption: 18mA (5V input, 8V output, no-load is less than 18mA. Higher the voltage, the greater the load current.)
Conversion Efficiency: Up to 92% (output voltage higher, the higher the efficiency)
Switching Frequency: 50KHz
Rectifier: Non-Synchronous Rectification
Module Properties: Non-isolated booster step up module
Short Circuit Protection: NONE
Operating Temperature: Industrial grade (-40 to 85 ) (output power 10W or less)

What you will receive:

1 x DC-DC Adjustable Step-up boost Power Converter Module XL6009 Replace LM2577
